| Basic Parameters | Tablet Size | 282×187×25mm | Packaging dimensions 315×220×77mm |
| Tablet Weight | 1220g | Total weight 2150g | |
| Device Color | Black | Material: PC+10%GF/Gray+TPU 85° | |
| Glass Cover | Corning Gorilla Glass 3rd Generation | ||
| Touch Screen | 10-point touch capacitive screen, hardness 7H | ||
| Display Screen | 10.1-inch FHD display, aspect ratio 16:10, resolution 1200×1920, brightness 550cd/m2 | ||
| I/O interface | Microphone×1 | ||
| Φ3.5mm Standard Headphone Jack ×1 | |||
| HDMI mini×1 | |||
| Type-C×1 | Data Only | ||
| USB×1 | 3 | ||
| DC_IN×1 | 19V/3.42A | ||
| RJ45×1 | Gigabit | ||
| COM port ×1 | Default RS232, replaceable with RS485 | ||
| TF/SIM combo card slot | TF supports up to 512GB, SIM supports China Mobile and China Broadcasting Network | ||
| Waterproof Speaker×1 | |||
| 12Pin Pogo Pin×1 | Use with optional charging dock | ||
| Camera | Front + Rear | 5.0MP+8.0MP | With flashlight |
| Battery | Capacity | 8000mAh/7.6V | Non-removable polymer lithium-ion battery |
| Battery Life | 7.5-8.5 Hours | 50% Volume / 50% Brightness / Play 1080P Video | |
| Communication | WiFi | WiFi 5 | 802.11a/b/g/n/ac, 2.4GHz+5.8GHz |
| Bluetooth | Bluetooth 4.2 | Transmission Distance 10m | |
| Network Port | RJ45 | 10/100/1000M Auto-Negotiation | |
| Performance | CPU | Intel Celeron N5100 | Alternatively, choose N100/N150*/10210Y/10510Y* |
| Operating System | Windows 10/11 Pro | Optional activation key | |
| Memory | 8G | DDR4 | |
| Storage | 128/256G | eMMC | |
| Optional Modules | Wireless Communication (3 in 1) | Full 4G, Global 4G, Full 5G | |
| Positioning (3 in 1) | Integrated multi-mode (GPS/BDS/GLONASS/Galileo/QZSS/NavIC) | ||
| Independent multi-mode (GPS/BDS/GLONASS), Independent single BeiDou (BDS) | |||
| Scan code | 1D Barcode, 2D Code (Newland N1) | ||
| NFC | Supports ISO14443A/14443B/15693 | ||
| Fingerprint | Screen Unlock | ||
| Standard Accessories | Adapter/Plug | AC100V~240V / Output DC19V/3.42A, plug options include Chinese, British, American, or European | |
| Wristband | Four-point Type | ||
| Optional Accessories | Activation key, charging dock, desktop stand, shoulder strap handle, VESA hole cover, tempered glass film, converter, stylus, car mount, carrying case | ||
| Reliability | Operating temperature | -20~60°C | |
| Storage temperature | -30~70℃ | ||
| Humidity | 95% Non-condensing | ||
| Drop height | 1.22m, Composite Wood Flooring, 6 Sides 4 Corners | ||
| Protection features | IP67 certification, UN38.3+MSDS for sea and air transport reports, EMC, safety regulations, RoHs, CE, battery 3C | ||
| Reminder: A set of three-proof tablet includes: 1) Tablet: Basic version (size + CPU + memory + storage) + optional modules; | |||
| 2) Accessories: Standard accessories (adapter/plug + wrist strap + manual, warranty card, certificate of conformity) + Optional accessories | |||
