| Model | TPM-L6070 | TPM-L6101 | TPM-L6104 | TPM-L6116 | |
| General Specifications | Control Button | OSD control keys on the rear panel, contrast ratio/brightness adjustable | OSD control keys on the rear panel, contrast ratio/brightness adjustable | OSD control keys on the rear panel, contrast ratio/brightness adjustable | OSD control keys on the rear panel, contrast ratio/brightness adjustable |
| Dimension(W×H×D) | 180.1mm×116.2mm×30mm | 262.3mm×180.9mm×43mm | 257.1mm×204.3mm×43mm | 301.7mm×191.1mm×43mm | |
| Cutout Dimensions(W×H) | 155.5mm×116mm | 248mm×166mm | 242mm×189mm | 287mm×177mm | |
| Housing | Aluminum milled panel + SGCC sheet metal structure; grounded isolation protection | Aluminum milled panel + SGCC sheet metal structure; grounded isolation protection | Aluminum milled panel + SGCC sheet metal structure; grounded isolation protection | Aluminum milled panel + SGCC sheet metal structure; grounded isolation protection | |
| Mounting Method | Embedded & VESA Mounting | Embedded & VESA Mounting | Embedded & VESA Mounting | Embedded & VESA Mounting | |
| Power Input | DC 12V Input | DC 12V Input | DC 12V Input | DC 12V~24V Input | |
| Power Consumption | 4W | 4.3W | 5.4W | 5.3W | |
| Display Interface | VGA&HDMI&DP | VGA&HDMI&DP | VGA&HDMI&DP | VGA&HDMI&DP | |
| Net Weight | 1.1kg | 1.21kg | 1.52kg | 1.62kg | |
| LCD | Screen Type | 7" SVGA TFT | 10.1" WXGA TFT | 10.4" XGA TFT | 11.6" FULL HD TFT |
| Resolution | 1024×600 | 1280×800 | 1024×768 | 1920×1080 | |
| Max. Colors | 16.7MB | 16.7MB | 16.7MB | 16.7MB | |
| Display Area(W×H) | 154.2mm×85.9mm | 217mm×135.6mm | 211.8mm×159mm | 256.3mm×144.2mm | |
| Backlight | WLED | WLED | WLED | WLED | |
| Pixel Pitch | 0.1506×0.1432 | 0.1695×0.1695 | 0.20625×0.20625 | 0.1335×0.1335 | |
| Brightness | 300cd/m² | 500cd/m² | 550cd/m² | 350cd/m² | |
| Contrast Ratio | 500:1 | 1300:1 | 1200:1 | 1000:1 | |
| View Angle(L/R/T/B) | 85/85/85/85 | 85/85/85/85 | 80/80/85/85 | 89/89/89/89 | |
| Touch Screen | Touch Screen Type | Multi-touch capacitive touch screen | Multi-touch capacitive touch screen | Multi-touch capacitive touch screen | Multi-touch capacitive touch screen |
| Light Transmittance | >85% | >85% | >85% | >85% | |
| Controller | USB Interface | USB Interface | USB Interface | USB Interface | |
| Operation System | Windows7, Windows8, Windows10, Linux | Windows7, Windows8, Windows10, Linux | Windows7, Windows8, Windows10, Linux | Windows7, Windows8, Windows10, Linux | |
| Response Time | <5ms | <5ms | <5ms | <5ms | |
| Surface Hardness | 7H | 7H | 7H | 7H | |
| Environment Parameters | Working Temp. | -20~60℃ | -20~60℃ | -20~60℃ | -20~60℃ |
| Storage Temp. | -20~70℃ | -20~70℃ | -20~70℃ | -20~70℃ | |
| Relative Humidity | 10-90%(No Condensing) | 10-90%(No Condensing) | 10-90%(No Condensing) | 10-90%(No Condensing) | |
| Vibration | 5~500Hz,1.5G,0.15mm | 5~500Hz,1.5G,0.15mm | 5~500Hz,1.5G,0.15mm | 5~500Hz,1.5G,0.15mm | |
| Shock | 10G, duration:11ms | 10G, duration:11ms | 10G, duration:11ms | 10G, duration:11ms | |
| EMC | CE/FCC Class B | CE/FCC Class B | CE/FCC Class B | CE/FCC Class B | |
| Waterproof Grade | Front panel complies with IP65 protection rating | Front panel complies with IP65 protection rating | Front panel complies with IP65 protection rating | Front panel complies with IP65 protection rating | |
| Model | TPM-L6121 | TPM-L6133 | TPM-L6150 | TPM-L6156 | |
| General Specifications | Control Button | OSD control keys on the rear panel, contrast ratio/brightness adjustable | OSD control keys on the rear panel, contrast ratio/brightness adjustable | OSD control keys on the rear panel, contrast ratio/brightness adjustable | OSD control keys on the rear panel, contrast ratio/brightness adjustable |
| Dimension(W×H×D) | 295mm×233.6mm×43mm | 339mm×224.2mm×43mm | 356mm×280mm×43mm | 388.4mm×237.6mm×43mm | |
| Cutout Dimensions(W×H) | 279mm×218mm | 324mm×210mm | 340mm×265mm | 374mm×224mm | |
| Housing | Aluminum milled panel + SGCC sheet metal structure; grounded isolation protection | Aluminum milled panel + SGCC sheet metal structure; grounded isolation protection | Aluminum milled panel + SGCC sheet metal structure; grounded isolation protection | Aluminum milled panel + SGCC sheet metal structure; grounded isolation protection | |
| Mounting Method | Embedded & VESA Mounting | Embedded & VESA Mounting | Embedded & VESA Mounting | Embedded & VESA Mounting | |
| Power Input | DC 12V Input | DC 12V~24V Input | DC 12V~24V Input | DC 12V~24V Input | |
| Power Consumption | 6.6W | 4.4W | 8.6W | 5.8W | |
| Display Interface | VGA&HDMI&DP | VGA&HDMI&DP | VGA&HDMI&DP | VGA&HDMI&DP | |
| Net Weight | 2.5kg | 1.92kg | 3.3kg | 2.3kg | |
| LCD | Screen Type | 12.1" XGA TFT | 13.3" FULL HD TFT | 15" XGA TFT | 15.6" FULL HD TFT |
| Resolution | 1024×768 | 1920×1080 | 1024×768 | 1920×1080 | |
| Max. Colors | 16.7MB | 16.7MB | 16.7MB | 16.7MB | |
| Display Area(W×H) | 246.8mm×185.3mm | 293.8mm×165.2mm | 305.5mm×229.5mm | 345.2mm×194.6mm | |
| Backlight | WLED | WLED | WLED | WLED | |
| Pixel Pitch | 0.08×0.24 | 0.051×0.153 | 0.099×0.297 | 0.17925×0.17925 | |
| Brightness | 500cd/m² | 250cd/m² | 400cd/m² | 400cd/m² | |
| Contrast Ratio | 1200:1 | 1200:1 | 1000:1 | 1000:1 | |
| View Angle(L/R/T/B) | 85/85/85/85 | 85/85/85/85 | 89/89/89/89 | 85/85/85/85 | |
| Touch Screen | Touch Screen Type | Multi-touch capacitive touch screen | Multi-touch capacitive touch screen | Multi-touch capacitive touch screen | Multi-touch capacitive touch screen |
| Light Transmittance | >85% | >85% | >85% | >85% | |
| Controller | USB Interface | USB Interface | USB Interface | USB Interface | |
| Operation System | Windows7, Windows8, Windows10, Linux | Windows7, Windows8, Windows10, Linux | Windows7, Windows8, Windows10, Linux | Windows7, Windows8, Windows10, Linux | |
| Response Time | <5ms | <5ms | <5ms | <5ms | |
| Surface Hardness | 7H | 7H | 7H | 7H | |
| Environment Parameters | Working Temp. | -20~60℃ | -20~60℃ | -20~60℃ | -20~60℃ |
| Storage Temp. | -20~70℃ | -20~70℃ | -20~70℃ | -20~70℃ | |
| Relative Humidity | 10-90%(No Condensing) | 10-90%(No Condensing) | 10-90%(No Condensing) | 10-90%(No Condensing) | |
| Vibration | 5~500Hz,1.5G,0.15mm | 5~500Hz,1.5G,0.15mm | 5~500Hz,1.5G,0.15mm | 5~500Hz,1.5G,0.15mm | |
| Shock | 10G, duration:11ms | 10G, duration:11ms | 10G, duration:11ms | 10G, duration:11ms | |
| EMC | CE/FCC Class B | CE/FCC Class B | CE/FCC Class B | CE/FCC Class B | |
| Waterproof Grade | Front panel complies with IP65 protection rating | Front panel complies with IP65 protection rating | Front panel complies with IP65 protection rating | Front panel complies with IP65 protection rating | |
| Model | TPM-L6170 | TPM-L6185 | TPM-L6190 | TPM-L6215 | |
| General Specifications | Control Button | OSD control keys on the rear panel, contrast ratio/brightness adjustable | OSD control keys on the rear panel, contrast ratio/brightness adjustable | OSD control keys on the rear panel, contrast ratio/brightness adjustable | OSD control keys on the rear panel, contrast ratio/brightness adjustable |
| Dimension(W×H×D) | 391.7mm×323.9mm×43mm | 454.3mm×296.8mm×43mm | 426.7mm×351.7mm×43mm | 526.2mm×317.7mm×43mm | |
| Cutout Dimensions(W×H) | 381mm×313mm | 440mm×282mm | 415mm×341mm | 511mm×308mm | |
| Housing | Aluminum milled panel + SGCC sheet metal structure; grounded isolation protection | Aluminum milled panel + SGCC sheet metal structure; grounded isolation protection | Aluminum milled panel + SGCC sheet metal structure; grounded isolation protection | Aluminum milled panel + SGCC sheet metal structure; grounded isolation protection | |
| Mounting Method | Embedded & VESA Mounting | Embedded & VESA Mounting | Embedded & VESA Mounting | Embedded & VESA Mounting | |
| Power Input | DC 12V Input | DC 12V-24V Input | DC 12V Input | DC 12V Input | |
| Power Consumption | 12W | 10W | 14W | 16W | |
| Display Interface | VGA&HDMI&DP | VGA&HDMI&DP | VGA&HDMI&DP | VGA&HDMI&DP | |
| Net Weight | 3.4kg | 3.2kg | 5.3kg | 6.8kg | |
| LCD | Screen Type | 17" SXGA TFT | 18.5" FULL HD TFT | 19" SXGA TFT | 21.5" FULL HD TFT |
| Resolution | 1280×1024 | 1920×1080 | 1280×1024 | 1920×1080 | |
| Max. Colors | 16.7MB | 16.7MB | 16.7MB | 16.7MB | |
| Display Area(W×H) | 338.9mm×271.3mm | 409mm×230mm | 375.8mm×300.8mm | 477mm×268.8mm | |
| Backlight | WLED | WLED | WLED | WLED | |
| Pixel Pitch | 0.264×0.264 | 0.213×0.213 | 0.0976×0.2928 | 0.08265×0.24795 | |
| Brightness | 250cd/m² | 300cd/m² | 250cd/m² | 250cd/m² | |
| Contrast Ratio | 1000:1 | 1000:1 | 1000:1 | 1300:1 | |
| View Angle(L/R/T/B) | 85/85/80/80 | 89/89/89/89 | 89/89/89/89 | 89/89/89/89 | |
| Touch Screen | Touch Screen Type | Multi-touch capacitive touch screen | Multi-touch capacitive touch screen | Multi-touch capacitive touch screen | Multi-touch capacitive touch screen |
| Light Transmittance | >85% | >85% | >85% | >85% | |
| Controller | USB Interface | USB Interface | USB Interface | USB Interface | |
| Operation System | Windows7, Windows8, Windows10, Linux | Windows7, Windows8, Windows10, Linux | Windows7, Windows8, Windows10, Linux | Windows7, Windows8, Windows10, Linux | |
| Response Time | <5ms | <5ms | <5ms | <5ms | |
| Surface Hardness | 7H | 7H | 7H | 7H | |
| Environment Parameters | Working Temp. | -20~60℃ | -20~60℃ | -20~60℃ | -20~60℃ |
| Storage Temp. | -20~70℃ | -20~70℃ | -20~70℃ | -20~70℃ | |
| Relative Humidity | 10-90%(No Condensing) | 10-90%(No Condensing) | 10-90%(No Condensing) | 10-90%(No Condensing) | |
| Vibration | 5~500Hz,1.5G,0.15mm | 5~500Hz,1.5G,0.15mm | 5~500Hz,1.5G,0.15mm | 5~500Hz,1.5G,0.15mm | |
| Shock | 10G, duration:11ms | 10G, duration:11ms | 10G, duration:11ms | 10G, duration:11ms | |
| EMC | CE/FCC Class B | CE/FCC Class B | CE/FCC Class B | CE/FCC Class B | |
| Waterproof Grade | Front panel complies with IP65 protection rating | Front panel complies with IP65 protection rating | Front panel complies with IP65 protection rating | Front panel complies with IP65 protection rating | |
