| Item | Specifications | |
| General Parameters | Processor | Quad-core ARM Cortex A55, 2.0GHz |
| Memory | 2GB/4GB DDR4 (default 2GB) | |
| Storage | 8GB/16GB/32GB/64GB eMMC (default 8GB) | |
| Operating System | Linux/Android | |
| Power Interface | Customizable according to needs | |
| Other Interfaces | M12-D/D-SUB9 (definition can be adjusted as needed) | |
| LCD screen | Screen Size | 12.1" |
| Resolution | 1024×768 | |
| Maximum Color | 16.7M , 72% NTSC | |
| Active Area (W×H) | 304.128x228.096mm | |
| Backlight | WLED | |
| Backlight MTBF (hours) | 50K hrs | |
| Response Time | 30(Typ.)(Tr+Td) ms | |
| Brightness | 350cd/m² | |
| Contrast | 1000∶1 | |
| Viewing Angle (L/R/T/B) | 89 / 89 / 89 / 89 | |
| Operating Temperature | -20℃-70℃ | |
| Storage Temperature | -20℃-70℃ | |
| Touch Screen | Material Type | resistive touch screen |
| Transmittance | 80%±3 | |
| Response Time | ＜15ms | |
| Operating Temperature | -10℃-70℃ | |
| Storage Temperature | -40℃-80℃ | |
| Surface Hardness | 3H | |
| Environmental Parameters | Electromagnetic Compatibility | Meets EN50121-3-2 Class A standard. |
| Vibration Shock | Meets EN50155-12.2.11 | |
| Power Input | DC9~36V/DC60~ 150V | |
| Software Parameters | System Software | Supports Linux buildroot 4.19 system |
| Application Software | The multimedia player supports playing network video streams and built-in video files, and supports customer customized communication protocols Adopts front-end and back-end decoupling technology, rapid UI iteration development, supports simultaneous configuration and upgrade of multiple devices. Support device feedback Support built-in file database and touch screen function Import and export files via USB flash drive. Real-time monitoring of CPU, eMMC, and memory information. |
|
