| Item | Specifications | |
| General Parameters | processor | Quad-core ARM Cortex A55, 2.0GHz |
| memory | 2GB/4GB DDR4 (default 2GB) | |
| storage | 8GB/16GB/32GB/64GB eMMC (default 8GB) | |
| operating system | Linux/Android | |
| power interface | Customizable according to needs | |
| other interfaces | M12-D/D-SUB9 (Definition can be adjusted as needed) | |
| LCD screen | screen size | 23.8" |
| resolution | 1920×1080 | |
| Maximum color | 16.7M , 99% sRGB | |
| Active area (W×H) | 527.04×296.46mm | |
| backlight | WLED | |
| Backlight MTBF (hours) | 30K hrs | |
| Response Time | 14(Typ.)(G to G) ms | |
| Brightness | 550cd/m² | |
| Contrast Ratio | 1000∶1 | |
| Perspective (L/R/T/B) | 89 / 89 / 89 / 89 | |
| Storage Temperature | -20 ~ 60℃ | |
| Operating Temperature | 0 ~ 50℃ | |
| Material Type | Standard | AG | AR (Three options available) | |
| Light Transmittance | 88-89% (Regular) | 82-86% (AG) | 94-97% (AR) | |
| Reflectivity | 11-12% (Normal) | 3-6% (AG) | 3-6% (AR) | |
| Protective Panel | Surface Hardness | 6H—7H |
| Stress | ＞90Mpa | |
| Temperature Resistance | -50 ~ 300℃ | |
| Environmental Parameters | Electromagnetic Compatibility | Meets EN50121-3-2 Class A standard |
| Vibration and Shock | Meet EN50155-12.2.11 | |
| Power Input | DC9~36V/DC60~ 150V/AC90~264V | |
| Software Parameters | System Software | Supports Linux buildroot 4.19 system |
| Application Software | Multimedia Player supports playing network video streams and built-in video files; supports customer-defined communication protocols Employs front-end and back-end decoupling technology, enabling rapid UI iteration development and supporting simultaneous configuration and upgrades for multiple devices Supports device echo Supports built-in file database Real-time monitoring of CPU, eMMC, and memory information |
|
