| Item | Specifications | |
| General Parameters | Processor | Quad-core ARM Cortex A55, 2.0GHz |
| Memory | 2GB/4GB DDR4 (default 2GB) | |
| Storage | 8GB/16GB/32GB/64GB eMMC (default 8GB) | |
| Operating System | Linux/Android | |
| Power Interface | Customizable according to requirements | |
| Other Interfaces | M12-D/D-SUB9 (definition can be adjusted as needed) | |
| LCD Screen | Screen Size | 17" |
| Resolution | 1280×1024 | |
| Maximum Colors | 16.7M , 72% NTSC | |
| Display area (W×H) | 337.92×270.336mm | |
| Backlight | WLED | |
| Backlight MTBF (hours) | 30K hrs | |
| Response Time | 20(Typ.)(Tr+Td) ms | |
| Brightness | 500cd/m² | |
| Contrast Ratio | 1000∶1 | |
| Viewing angle (L/R/T/B) | 89 / 89 / 89 / 89 | |
| Storage Temperature | -20 ~ 70℃ | |
| Operating Temperature | -20 ~ 70℃ | |
| Material Type | Normal| AG | AR (three options) | |
| Light Transmittance | 88—89% (normal)| 82-86% (AG) | 94-97% (AR) | |
| Reflectivity | 11-12% (Normal) | 3-6% (AG) | 3-6% (AR) | |
| Protective Panel | Surface Hardness | 6H—7H |
| Stress | ＞90Mpa | |
| Temperature Resistance | -50 ~ 300℃ | |
| Environmental Parameters | Electromagnetic Compatibility | Meets EN50121-3-2 Class A standard. |
| Vibration and Shock | Meets EN50155-12.2.11 | |
| Power Input | DC9~36V/DC60~ 150V/AC90~264V | |
| Software Parameters | System Software | Supports Linux buildroot 4.19 system |
| Application Software | Multimedia Player supports playing network video streams and built-in video files; supports customer-defined communication protocols Employs front-end and back-end decoupling technology, enabling rapid UI iteration and supporting simultaneous configuration and upgrades for multiple devices Supports Device Reflection Supports Built-in File Database Real-time monitoring of CPU, eMMC, and memory information |
|
