| Item | Specifications | ||
| General Parameters | Processor | Quad-core ARM Cortex A55, 2.0GHz | |
| Memory | 2GB/4GB DDR4 (default 2GB) | ||
| Storage | 8GB/16GB/32GB/64GB eMMC (default 8GB) | ||
| Operating System | Linux/Android | ||
| Power Interface | Customizable according to requirements | ||
| Other Interfaces | M12-D/D-SUB9 (Definition can be adjusted as needed) | ||
| LCD Screen | Screen Size | 32" | |
| Resolution | 1920×1080 | ||
| Maximum Colors | 16.7MB | ||
| Display area (W×H) | 698.4×392.85mm | ||
| Backlight | DLED/ELED | ||
| Backlight MTBF (hours) | 50K hrs | ||
| Response Time | 15(Typ.)(G to G) ms | ||
| Brightness | 700cd/m² | ||
| Contrast Ratio | 1200∶1 | ||
| Viewing angle (L/R/T/B) | 89 / 89 / 89 / 89 | ||
| Storage Temperature | -20 ~ 70℃ | ||
| Operating Temperature | -20 ~ 70℃ | ||
| Protective Panel | Material Type | Mirror Capacitive Touch Screen | |
| Light Transmittance | 30%±5 | ||
| Reflectivity | 70%±5 | ||
| Surface Hardness | 6H | ||
| Environmental Parameters | Electromagnetic Compatibility | Meets EN50121-3-2 Class A standard. | |
| Vibration and Shock | Meets EN50155-12.2.11 | ||
| Power Input | DC9~36V/DC60~ 150V/AC90~264V | ||
| Software Parameters | System Software | Supports Linux buildroot 4.19 system | |
| Application Software | Supports Customer-Defined Communication Protocols Adopting front-end and back-end decoupling technology, the rapid iterative development of UI supports simultaneous configuration and upgrade of multiple devices Supports Device Reflection Supports Built-in File Database Real-time monitoring of CPU, eMMC, and memory information, etc. |
||
