| Item | Specifications | |
| General Parameters | Processor | 8th Generation Intel® Core™ i5-8265U |
| Memory | Onboard DDR4-8G | |
| Storage | 1 x M.2 Key-M Slot (SATA/NVME, 2280) | |
| Operating System | Linux/Microsoft Windows | |
| Power Interface | DC12V input | |
| Other Interfaces | 3*USB3.0/1*USB2.0/HDMI1/HDMI2/HDMI3/LAN1/LAN2/COM1: RS232/RS485/COM2: RS232 and other interfaces | |
| WIFI | Wi-Fi 6 802.11ax, 2.4GHz/5GHz dual-band | |
| Watchdog | 1~255 Programmable Settings | |
| Power Supply | Input Voltage | DC12V ±10% |
| Total Power Consumption | TDP 35W-45W | |
| Mechanical Parameters | Structure | Fully Enclosed Aluminum Profile Shell |
| Dimensions | (L)214mm x (W)165mm x (H)43mm | |
| Environmental Parameters | Operating Temperature | -10ºC ~ 50ºC (using SSD) |
| Storage Temperature | -20ºC ~ 70ºC (using SSD) | |
| Relative Humidity | 5~95% (Non-condensing) | |
| Vibration | Using SSD: 5~500Hz, 1.5Grms, conforming to IEC60068-2-64 | |
| Impact | Using a 20GB SSD (11ms duration, half-sine wave), conforming to IEC60068-2-27 | |
| EMC | CE/FCC Class B |
