| Item | Specifications | ||
| General Parameters | Processor | Quad-core ARM Cortex A55, 2.0GHz | |
| Memory | 2GB/4GB DDR4 (default 2GB) | ||
| Storage | 8GB/16GB/32GB eMMC (default 8GB) | ||
| Operating System | Linux/Android | ||
| Power Interface | Customizable according to requirements | ||
| Other Interfaces | M12-D/D-SUB9/SDI/USB (interface can be customized upon request) | ||
| Environmental Parameters | Electromagnetic Compatibility | Meets the EN50121-3-2 Class A standard. | |
| Vibration and Shock | Meets the EN50155-12.2.11 standard. | ||
| Power Input | DC9~36V/DC60~ 150V/AC90~264V | ||
| Software Parameters | System Software | Supports Linux buildroot 4.19 system | |
| Application Software | Supports built-in multimedia player | ||
| Supports external m-SATA and standard SATA hard drives and supports 485 communication. | |||
| Support USB interface communication Support Ethernet communication Support TF card | |||
| Supports 4G wireless communication via USB flash drive file import/export. | |||
| Support WiFi wireless communication | |||
| Supports HDMI/VGA/LVDS video format output | |||
