| Resolution | 3840 X 160 | Luminance | 500cd/㎡ |
| Outline Dim. | 1211.2 (W) × 67.5 (H) × 24.3(D) mm | Contrast Ratio | 1000:1 (Typ.) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Response Time | 8 (Typ.)(Tr/Td) ms |
| Power Supply | 12V(Typ.) | Weight | 2.72Kg |
| System Configuration | |||
| OS | Android 5.11 | CPU | S700,Quad-core A53 SMP4,28nm |
| RAM | 2GB | Storage | 8GB |
| Connection | Micro USB × 1 / Mini RJ45 × 1 / HDMI × 1 / TYPE-C × 1 /TF Card × 1 / 安卓HDMI IN切换键 × 1 |
||
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C | ||
