| Resolution | 1920 × 540 | Luminance | 700cd/㎡ |
| Outline Dim. | 720.8 (W) × 226.25 (H) ×42.3(D) mm | Contrast Ratio | 1200:1 (Typ.) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Response Time | 8 (Typ.)(Tr/Td) ms |
| Power Supply | 12.0V (Typ.) | Weight | 4.82Kg |
| System Configuration | |||
| OS | Android 7.1 | CPU | A40I,Quad-core ARM,Cortex A7,1.2G |
| RAM | 1GB | Storage | 8GB |
| Connection | USB OTG × 1 / USB Host × 1 / RJ45 × 1 / TF Card × 1 / RESET× 1/Earphone× 1 |
||
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C | ||
