| Resolution |
1920 × 360 |
Luminance |
300cd/㎡ |
| Outline Dim. |
616.7 (W) × 136.1 (H) × 50 (D) mm |
Contrast Ratio |
1200:1 (Typ.) |
| Viewing Angle |
89/89/89/89 (Typ.)(CR≥10) |
Response Time |
8 (Typ.)(Tr/Td) ms |
| Power Supply |
12.0V (Typ.) |
Weight |
5.5Kg |
| System Configuration |
| OS |
Android 7.1 |
CPU |
RK3288,Quad-core ARM Cortex-A17,1.8GHz,28nm |
| RAM |
2GB |
Storage |
8GB |
| Connection |
RJ12 × 1 / RJ11 × 1 / Line OUT × 1 / RJ45× 1 USB ×4 / Micro USB × 1 / TF Card × 1 / SIM Card × 1 / DC_IN × 1
|
| Environment |
Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
