| Resolution | 1920 × 1920 | Luminance | 500cd/㎡ |
| Outline Dim. | 411.96 (W) × 411.96 (H) × 25.1 (D) mm | Contrast Ratio | 1000:1 (Typ.) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Response Time | 8 (Typ.)(Tr/Td) ms |
| Power Supply | 12.0V (Typ.) | Weight | 1.95Kg |
| System Configuration | |||
| OS | Android 7.1 | CPU | Rockchip RK3288 Quad-core CortexA17,1.8GHz |
| RAM | 2GB | Storage | 8GB |
| Connection | USB × 2 / HDMI OUT × 1 / HP × 1 / RJ45× 1/ DC IN × 1 | ||
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C | ||
