| Resolution | 1366 × 238 | Luminance | 700cd/㎡ |
| Outline Dim. | 432.3 (W) × 93.9 (H) × 17.8 (D) mm | Contrast Ratio | 3000:1 (Typ.) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Response Time | 8 (Typ.)(Tr/Td) ms |
| Power Supply | 12.0V (Typ.) | Weight | 0.7Kg |
| System Configuration | |||
| OS | Android 6.0 | CPU | Allwinner A40I,Quad-core ARM,Cortex-A7, 1.2GHz; |
| RAM | 1GB | Storage | 8GB |
| Connection | Micro USB × 1 /USB Host× 2 / DC × 1 | ||
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C | ||
